GIGABYTE Z170-HD3 Intel Z170 Soket 1151 DDR4 3466 (O.C)MHz HDMI-DVI-VGA

Birinci Sınıf PCIe hattı ile 2-Yollu Grafik


6. Jenerasyon Intel® Core™ İşlemci Desteği


Çift Kanal DDR4, 4 DIMMs


32Gb/s Veri Transferi ile PCIe Gen3 x4 M.2 Konnektör (PCIe & SATA SSD desteği)


16Gb/s' a kadar Veri Transferi için 3 SATA Express Konnektör


Yüksek Kaliteli Ses Kapasitörleri ile 8 kanal HD Ses


LED İz Yolu Aydınlatması ile Ses Gürültü Koruması


Realtek® Green GbE LAN ile cFosSpeed Internet Hızlandırma Yazılımı


GIGABYTE UEFI DualBIOS™ teknolojisi

İşlemci

Support for 7th/6th Generation Intel® Core™ i7 processors/Intel® Core™ i5 processors/ Intel® Core™ i3 processors/Intel® Pentium® processors/ Intel® Celeron® processors in the LGA1151 package

* For 7th Generation Intel® Core™ processors support need to update the latest BIOS.

L3 cache varies with CPU

(Please refer "CPU Support List" for more information.)

Yongaseti

Intel® Z170 Express Chipset

Bellek

4 x DDR4 DIMM sockets supporting up to 64 GB of system memory

* Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.

Dual channel memory architecture

Support for DDR4 3466(O.C.) /3400(O.C.) /3333(O.C.) /3300(O.C.) /3200(O.C.) /3000(O.C.) /2800(O.C.) /2666(O.C.) /2400(O.C.) /2133 MHz memory modules

Support for ECC UDIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

Support for non-ECC UDIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme Memory Profile (XMP) memory modules

(Please refer "Memory Support List" for more information.)

Dahili Grafik

Integrated Graphics Processor- Intel® HD Graphics support:

1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz

1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz

* The DVI-D port does not support D-Sub connection by adapter.

1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz

* Support for HDMI 1.4 version.

Support for up to 3 displays at the same time

Maximum shared memory of 1024 MB

Ses Desteği

Realtek® ALC887 codec

High Definition Audio

2/4/5.1/7.1-channel

Support for S/PDIF Out

LAN

Realtek® GbE LAN chip (10/100/1000 Mbit)

Genişleme Yuvaları

1 x PCI Express x16 slot, running at x16 (PCIEX16)

* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.

1 x PCI Express x16 slot, running at x4 (PCIEX4)

2 x PCI Express x1 slots

(All of the PCI Express slots conform to PCI Express 3.0 standard.)

2 x PCI slots

Çoklu Grafik Teknolojisi

Support for 2-Way AMD CrossFire™ technology

Depolama Ara yüzü

Chipset:

1 x M.2 Socket 3 connector (Socket 3, M key, type 2242/2260/2280 SATA & PCIe x4/x2/x1 SSD support)

3 x SATA Express connectors

6 x SATA 6Gb/s connectors

Support for RAID 0, RAID 1, RAID 5, and RAID 10

* Refer to "1-7 Internal Connectors," for the supported configurations with the M.2, SATA Express, and SATA connectors.

USB

Chipset:

8 x USB 3.0/2.0 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

Dahili G/Ç Bağlantı Noktaları

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x M.2 Socket 3 connector

3 x SATA Express connectors

6 x SATA 6Gb/s connectors

1 x CPU fan header

3 x system fan headers

1 x front panel header

1 x front panel audio header

1 x S/PDIF Out header

2 x USB 3.0/2.0 headers

2 x USB 2.0/1.1 headers

1 x Trusted Platform Module (TPM) header

1 x Thunderbolt™ add-in card connector

1 x serial port header

1 x parallel port header

1 x Clear CMOS jumper

Arka Panel G/Ç

1 x PS/2 keyboard/mouse port

1 x D-Sub port

1 x DVI-D port

1 x HDMI port

4 x USB 3.0/2.0 ports

2 x USB 2.0/1.1 ports

1 x RJ-45 port

6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In)

G/Ç Denetleyicisi

iTE® I/O Controller Chip
